CNC processing
- Precision turned parts of all kinds according to DIN, drawing or sample at outside diameter from 5 to 210 mm
- Bar turning up to a diameter of 65 mm, turning of parts using jaw chuck up to a diameter of 210 mm
- Batch sizes: small, mid-volume and large, from 10 to approx. 20.000 pieces
- Tolerances for turned parts ± 0,015 mm; turned surfaces Rmax 4µm; concentricity of all turned diameters to each other within 0,015 mm guaranteed
- Complex machining of 4 faces at one set-up on vertical machining center
- Re-stamping with material certificate subject to DIN EN 10204 ( 2.1 ; 2.2 ; 3.1 ) Re-stamping is done upon approval by TÜV Rheinland Industrie Service GmbH according to the agreement 9-153(H)
Material Processing
- sawing up to a diameter of 260 mm and length of 6000 mm
- welding
- assembly
- laser marking
- needle embossing
Upper-
area-
editing
Zinking, nickel plating, copper plating, chroming, phosphating, chromating, black-finishing, anodizing, coating, glass bead blasting, corundum blasting
Additional services
- Component assembly, mounting of components
- Galvanic- and blasted surfaces
- Heat treatment
- Bonding
- Welding
Materials
We machine all materials such as free-cutting steel, stainless steel, aluminium and brass.
